VNIR-S HYPERSPEKTRALKAMERA
Spektralbereich:
400-1000nm
Spektrale Auflösung:
8nm
Kostengünstige, hochleistungsfähige Hyperspektralkamera der Einstiegsklasse - geeignet für eine Vielzahl von Forschungs-, Feld- und Industrieanwendungen.
Voll kompatibel mit all unseren
Hyperspektrale Scanlösungenund geeignet
Objektivlinsen
.
TECHNISCHE SPEZIFIKATIONEN
Note: technical specifications can vary dramatically based on many factors i.e. lens being used, application parameters etc. The figures below show the specifications of the camera operating under typical/expected conditions.
SPEKTRALBEREICH
400-1000nm
Spektrale Auflösung
Typisch: 8 nm
SPEKTRALE DISPERSION
1,0 nm/Pixel
SPECTRAL BANDS FROM RLD
892/446/223
SPECTRAL BANDS FROM OSR
75
NEIN. PIXEL IM CROSS-TRACK
1400
LINE FRAME RATE
100 lf/s
LÄCHELN UND TRAPEZFEHLER
Subpixel über das Ausgabefeld des Spektrographen
